Description
Basic Info.
| Production Capacity | 1000sets/Year |
Product Description
Product DescriptionAsphalt mixing plant burner is a burner specially used for asphalt mixing equipment. The equipment iscompact in structure and reasonable in design. After many optimizations, it can be applied to asphalt mixing plants of various layouts and is convenient for movement, installation and maintenance.Product Parameters
| Matching asphalt machine | 1000 | 1500 | 2000 | 3000 | 4000 | 5000 |
| Burner model | BYA-1000 | BYA-1500 | BYA-2000 | BYA-3000 | BYA-4000 | BYA-5000 |
| Output power(Kw) | 6410 | 9680 | 12840 | 19260 | 25500 | 31620 |
| Output power(Mcal) | 5520 | 8330 | 11050 | 16570 | 21930 | 27200 |
| Pump pressure(MPa) | 1.2 | 1.2 | 1.2 | 1.2 | 1.2 | 1.2 |
| Max oil consumption(kg/h) | 600 | 900 | 1200 | 1800 | 2400 | 3000 |
| Max gas consumption(m³/h) | 700 | 1100 | 1500 | 2100 | 3000 | 4000 |
| Air volume(m³/h) | 650 | 980 | 1300 | 1950 | 2580 | 3200 |
| Air pressure(kpa) | 15~25 | 15~25 | 15~25 | 15~25 | 15~25 | 15~25 |
| Gas pipeline | 65A | 80A | 100A | 150A | 150A | 150A |
1. Control mode: electronic proportional adjustment, double frequency conversion control
2. Ignition method: high voltage electronic ignition, independent gas ignition gun
3. Applicable fuel: light/heavy/residue oil , gas
4. Oil volume adjustment: According to the set output power, the oil supply volume is automatically adjusted according to the set ratio.
5. Air volume adjustment: frequency conversion proportional control, automatically output air volume according to the set ratio.
6. Oil pump output pressure: 1-6 bar adjustable
7. Oil pump (domestic) power: 1.5 KW
8. Fuel requirements: high calorific value, good combustion performance, moderate viscosity, corrosiveness and small solid impurities, easy to store and transport.
Baoyuan Machinery is a comprehensive enterprise that comprises R& D, test, manufacture, sales and service functions. We have succeeded in researching and supplying solutions with the following equipment: Drying equipment, activated carbon production equipment, building materials equipment, beneficiation equipment, crushing equipment and other products.
With our leading-edge technologies, advanced processing equipment and our corporate spirit of "innovation, pragmatism, unity, hard work and dedication", our company has the strength to meet the challenges from all aspects. We have the confidence to build "Baoyuan" into a world-renowned brand, provide quality services for the dryer and building processing industry, and achieve a win-win situation between the company and customers.
Our Contact
